    Medium Enterprise - K8

    The following section provides recommended sizing to support enterprise with the following parameters:

    • Use case: IGA
    • Maximum number of user: 4500
    • Number application integrations: up to 30
    • Maximum number of entitlements across integrated applications: 25,000
    • Maximum number of concurrent user sessions: 175
    • Assumes that background processes are running to support synchronization

    AWS Sizing

    Platform componentQtyCPURAM (GB)Storage~ Cost per month
    Amazon EKS Cluster
    $73-
    -> Worker nodes - m4.2xlarge3832200GB
    $672-
    RDS Postgres (db.t3.2xlarge)2832400GB
    $508-
    Neptune - Gremlin+Cassandra (db.r5.large)2216100GB
    $518-
    Elasticache Redis (cache.m5.xlarge)1412.93
    $155-
    Windows Connector VM (m5.xlarge)1416100GB
    $246
    Estimated monthly platform cost
    $2172-
    • Cost is based on the AWS calculator with 1 year reservation. Does not include data transfer and traffic related fees

    Small k8 deployment on AWS

    Azure Sizing

    Platform componentQtyCPURAM (GB)Storage
    AKS Cluster
    -> Worker nodes - _D8s_v53832200GB
    Azure database for Postgres D8ds v5 8vCore - HA Enabled - 3000 IOPS14200GB
    Azure managed instance for Cassandra (D2s)128
    Azure cache for Redis (Premium P2)1216

    OpenIAM Pod Memory Sizing

    The table below describes the recommended sizing for each of teh following pods

    Platform componentRAM (GB)
    Workflow2.0
    UI6.0
    Synchronization0.8
    Elasticsearch4.0
    Consul0.5
    Auth Manager2
    Business rules manager0.5
    Device manager0.5
    Email manager0.5
    ESB2.0
    Groovy manager2.0
    IDM2.0
    RabbitMQ3.0
    Reconciliation0.8
    rProxy0.5
    Vault0.5
    jdbc-connector-rabbitmq0.25
    ldap-connector-rabbitmq0.25
    linux-connector-rabbitmq0.25
    scim-connector-rabbitmq0.25
    Kibana1.0
